High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate

$High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate$

$High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate$

Large Image : High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate

Product Details:

Place of Origin:	Henan, China
Brand Name:	RONGSHENG
Certification:	ISO9001

Contact Now

High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate

Description

SiO2 Content (%):	International Standard	Al2O3 Content (%):	None
MgO Content (%):	0.18%	CaO Content (%):	None
CrO Content (%):	0.002%	SiC Content (%):	90-93.89%
Highlight:	Silicon Carbide Kiln Shelves , Refractory Sic Ceramic Plate , Refractory Silicon Carbide Kiln Shelves

High Temperature Resistance Silicon Carbide Kiln Shelves High Strength Refractory Sic Ceramic Plate

SiC Kiln Plate Description


Silicon carbide plate used the high purity silicon carbide(SIC) and industrial silicon powder as the primary materials.Shaped by vibration,made by high sintering.

Silicon carbide plate silicon carbide bricks, sheds, brackets and silicon carbide special-shaped parts produced with silicon carbide as the main raw material not only have the inherent characteristics of silicon carbide such as high strength and high hardness, but also have high refractoriness under load, fast heat conduction, anti-oxidation, It is not easy to shrink and deform under high temperature, and has the characteristics of long service life.
Features of SiC Kiln Plate:
1. High strength. 2. Excellent wear resistance. 3. Good thermal conductivity. 4. Low thermal expansion. 5. Good thermal shock stability.

Product Advantage

$High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate 0$

Product Application

Application of SiC Kiln Plate:

1. Non-ferrous metal smelting industry,ceramic,enamel and cement rotary kiln mouth, as well as glass annealing furnace and various kind of high temperature furnace. 2. Blast furnace lining,the lining of aluminium electrolytic bath,glass tank,structural ceramics,sanitary ceramics,domestic ceramics,electrotechnical porcelain refractory material, sinter powder metal industry. 3. Industrial ceramics bearing plate burning,pushing board, sagger; muff plate of annealing furnace;lining and ignitor of CFBB; lining of garbage incinerators,heat treatment electric heating furnace,soaking pit furnace etc.

$High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate 1$

Specification

$High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate 2$

$High Temperature Resistance Silicon Carbide Kiln Shelves Refractory Sic Ceramic Plate 3$

Properites	Units	Silicon carbide Material
Type		SiC		SiSiC	NSiC	RSiC
Chemical composition	SiC%	89	87	92	70	99
	SiO2 %	5	6	-	Si3N4 28	-
	Al2O3%	1.0	2.0	-	-	-
Bulk Desity	g/cm3	2.85	2.8	3.01	2.8	2.75
Apparent porosity	%	12	14	0.1	12	14
M.O.R.@20℃	MPa	50	48	260	180	100
M.O.R.@1300℃	MPa	58	56	280	185	120
C.T.E.@20℃-1000℃	10-6K-1	4.8	4.2	4.5	4.7	4.6
C.C.S	MPa	100	90	900	500	300
Thermal shock resistance	★	★★★★★	★★★★★	★★★★★	★★★★★	★★★★★
Max working temperature	℃	1450	1420	1300	1500	1650
application	Used in ceramic shuttle kiln, tunnel kiln and roller kiln,Kiln furniture.
